Static Fines Clean Up

Static Fines Clean Up

CRS patented Screen design was developed to deal with most troublesome materials, built on the principle, heavier materials go further than lighter materials if the same force is applied.

Product Brochure
Enquire

CRS patented Screen design was developed to deal with most troublesome materials, built on the principle, heavier materials go further than lighter materials if the same force is applied.  CRS design, engineer and manufacture a screen which propels material upwards and outwards with a huge force so that the material can get time to untangle and separate, at the same time catapulting the heavier material forward, leaving the lighter material behind for fine screening. This is possible because of the “direct drive system” CRS power both sections of their screen so there is no slowing down of the snapping action.

The speed of the Screen is variable, which allows separation to take place in a variety of materials. The angle of the screen is adjustable from 13 – 19 degrees to also aid in separation.

Whether it is the KF 44 – 18 Tracked Mobile, or the 4.4 meter, 6 meter, or 8 meter Static Installations, one major design remains constant, how the material is violently agitated and screened on the Kinetic Flow Screen before being dampened or decelerated on our Mono Layer Tray before entering the Air Separation Unit, this gives time for material to spread across the tray and insures an even and measured feed into the separation chamber. CRS are the only company to use this method, most all others use a conveyor to feed their chamber which produces a thick or deep feed of material, resulting in them having to use high kilowatt fans just to try and blow through the material resulting in higher running costs and inacurate separation.

CRS design, manufacture and install Static Trommel Fines Recovery Plants separating paper and plastics from aggregate and fine materials. CRS Trommel Fines drastically reduces landfill costs by segregating the fines from papers and plastics as well as extracting the aggregates.

Static Fines Clean Up
CRS Static Fines Plant

Fines Recovery Systems – Features & Benefits

  • 1.8m screen width x 6.0m screen length
  • Air separation unit separates the light and heavy fractions
  • Unique Patented direct drive system driving both decks ensuring maximum agitation
  • Self cleaning screens as apertures in the unit vibrate and stretch slightly resulting in clean screens and products
  • High screening efficiency

Recirculating System?: 0

Type: jaw

Bogey Option: 0

Conver Rotator: 0
